Der PHOTON Newton Reflektor mit 150 mm Öffnung und dem Öffnungsverhältnis f/6 ist für die Beobachtung und Planetenfotografie optimiert - ein ideales Einsteigerteleskop

• Öffnung 150 mm / Brennweite 900 mm / Öffnungsverhältnis F6
• Hochwertiger parabolischer Hauptspiegel mit 94 % Verspiegelung für ein helleres Bild.
• Großer Fangspiegel mit 45 mm Durchmesser - wenig Abschattung für scharfe Mond- und Planetenbeobachtungen
• Präziser 2" Crayford Okularauszug für genaues Scharfstellen - Motorfokus ist optional erhältlich.
• Carbon Tubus für mehr Stabilität bei gleichzeitig besserem Transport - Made in Germany!
• Justierbare Haupt- und Fangspiegelhalterung aus Metall, praktische Justierhilfe am Hauptspiegel.
• Fokusposition ist für die Beobachtung optimiert, Sie werden mit allen Okularen problemlos scharfstellen können.
• Das Teleskop wird von kleineren Montierungen wie der EQ3 oder EQ5 von Skywatcher noch gut getragen
• Zentralmarkierung am Hauptspiegel für problemlose Justage vorhanden
• Umfangreicher Lieferumfang: 6x30 Sucher, Rohrschellen, Prismenschiene

The Geoptik Dovetail Clamp can easily be adapted to different mounts and offers a solid clamping of dovetail bars.

• clamps Losmandy style and Vixen style dovetail bars
• area clamping for better stability
• matches directly to the Skywatcher AZ-EQ5 - without intermediate adapter (image at left)
• fits to other mounts by using a conversion adapter

The PHOTON Newtonian reflector with 150 mm aperture and an f-ratio of f/5 is well suited for observation and astrophotography and an ideal beginner´s telescope.

• Aperture 150 mm / Focal length 750 mm / F-ratio F5
• High-quality parabolic primary mirror with 94% reflection coating for a brighter image.
• Large secondary mirror with 63 mm diameter for a well illuminated image field for astrophotography
• Precise 2" Crayford focuser for accurate focusing and micro transmission - motorfocus optional.
• Carbon tube for more stability with better portability at the same time - Made in Germany!
• Adjustable primary and secondary mirror holder made of metal, convenient collimation marking on primary mirror
• Focus position optimized for observation with all customary eyepieces and for astrophotography with coma correctors
• Due to its short build the Newtonian is suitable for smaller mounts (Skywatcher EQ3 upwards)
• Central mark on the primary mirror for easy collimation
• Generous equipment: 6x30 finder scope, ring clamps, dovetail included

The 140 mm f/6.5 triplet apochromat convinces with a pure color image and a powerful 4" RAP focuser.

• Aperture 140 mm
• Focal length 910 mm
• Fast focal ratio f/6.5
• Air-spaced triplet objective - 2 ED elements provide an image free from chromatic aberration
• Solid 4" rack and pinion focuser with dual speed - ideal for astrophotography
• Intermediate threads for screwed adaptations, e.g. M68x1 female thread
• Retractable dew shield
• CNC tube rings, carrying handle and dovetail bar are included in the scope of delivery
• Carbon tube for easier transport and high stability
• Delivery in transport case
• Every apochromat is tested by the manufacturer and Teleskop-Service before shipment
• Each apo receives a serial number and is delivered with a photographical test certificate

TS PHOTOLINE 96 mm f/6 triplet apochromat with color-clean image - high quality triplet objective from Japanese production.

• Aperture 96 mm / focal length 576 mm / focal ratio f/6
• Multi-coated 3-element lens with FCD100 APO element (similar to FPL53) from Hoya (Japan) for a color-pure image
• Lens including cell is made in Japan
• Internal baffles for higher contrast and against reflections
• 2.5" RAP dual-speed focuser with improved draw tube bearing - carries accessories up to 10 kg without shifting
• Connection for screw adaptations via M63x1 female thread, 2" and 1.25" receptacle
  Retractable dew shield for transport
• CNC tube rings, Vixen/EQ5 style dovetail bars on both sides and finder shoe are included in delivery
• Each apo is tested and optimized at our optical bench before shipping

TS PHOTOLINE 106 mm f/6.6 triplet apochromat with color-clean image with high-quality triplet lens from Japanese production

• Aperture 106 mm / focal length 700 mm / focal ratio f/6.6
• Multi-coated 3-element lens with FCD100 APO element (similar to FPL53) from Hoya (Japan) for a color-pure image
• The lens including cell is made in Japan
• Lens is adjustable with pull and push screws
• Internal baffles for higher contrast and fewer reflections
• 3.5" dual-speed RAP focuser with improved bearing of the draw tube - supports cameras up to 10 kg without shifting
• Connection for screw adaptions via M63x1 female thread - 2" and 1.25" receptacle
• Powerful telescope also for observing with clear, high contrast image
• Retractable dew shield for transport
• CNC tube rings, Vixen/EQ5 style dovetail bar, carrying handle and finder shoe are included in the scope of delivery
• Each Apo is visually and mechanically inspected and tested before shipment
• Includes 3" 0.75x field corrector - improves focal ratio to f/4.95 with full correction to full frame


The Photoline corrector is optimized for the TS 85 mm f/6 APO and ED refractor telescopes and corrects the field of view for astrophotography up to full frame format.

• Shortening factor 0.92x
• Connection telescope side: M63x1 male thread
• Connection camera side: M48x0.75 male thread
• Working distance: 55 mm from the connection thread
• ED design for good correction on axis and in the field
• The corrector is optimized for all refractors with 85 mm aperture and f/6, but it will also give good results with similar telescopes.

TS PHOTOLINE 85 mm f/6 triplet apochromat with color-clean image - high quality triplet objective from Japanese production.

• Aperture 85 mm / focal length 510 mm / focal ratio f/6
• Multi-coated 3-element lens with FCD100 APO element (similar to FPL53) from Hoya (Japan) for a color-pure image
• Lens including cell is made in Japan
• Internal baffles for higher contrast and against reflections
• 2.5" RAP dual-speed focuser with improved draw tube bearing - carries accessories up to 10 kg without shifting
• Connection for screw adaptations via M63x1 female thread, 2" and 1.25" receptacle
• Retractable dew shield for transport
• CNC tube rings, Vixen/EQ5 style dovetail bars on both sides and finder shoe are included in delivery
• Each apo is tested and optimized at our optical bench before shipping

The new TS Photoline 150 mm f/8 Apo convinces with its high optical performance, neat chromatic correction and very good mechanics - with large 3.7" focuser for astrophotography with large sensors

• Aperture 150 mm / focal length 1200 mm / focal ratio f/8
• Very good chromatic correction due to color-pure imaging by "Extra-Low-Dispersion" FPL53 APO element from Ohara (Japan) and lanthanum glass element
• Fast cooling due to the 2-element objective design
• With only 9.5 kg the telescope is still transportable and can be carried by mounts from EQ6 upwards
• 3.7" focuser with 360° rotation - rack and pinion - one of the best focusers in its class
• Multi-coated objective and inner baffles for optimal contrast
• M92x1 and M68x1 female threads are available for screw adaptions - illumination up to full frame format is given
• Working distance 130 mm from the 2" receptacle or 230 mm without extension between focuser and tube
• Slide-in dew shield, CNC tube rings, finder shoe, dovetail bar and carrying handle are included in the scope of delivery
• Suitable correctors and focal length reducers for astrophotography are available
• Each apo is checked and optimally adjusted on the optical bench at Teleskop-Service before shipment. Upon request, we will send an optics test (stellar imaging focal, extrafocal, intrafocal and Ronchi) with it.

The fast 50 mm refractor with the improved ED 50 mm objective can be used as a travel telescope, spotting scope and guiding scope.

• Excellent image due to the 50 mm f/4 ED lens with blackened edges
• Straight view and adaptation of star diagonal mirrors or Amici prisms possible due to detachable tube
• High-quality Crayford focuser with 1.25" compression ring and T2 connection - supports up to 2 kg
• CNC tube rings with multi-function plate included
  Telescope fits in standard finder shoes (Skywatcher, Vixen, GSO, TS-Optics ...)
• 3/8" photo thread is available at the base. With a 1/4" reducer the adaption to any tilt and ball heads is also possible

The TS 4-element 62mm aperture refractor is a versatile spotting scope and telescope, a 520mm telephoto objective and a powerful guide scope for astrophotography.

• aperture 62 mm
• Focal length 520 mm -- Focal ratio f/8.4
• 4-element design for sharp imaging of moon, planets and deep-sky objects, but also daytime observing
• a versatile travel telescope for observing and photography due to a flat field of view
• sensitive Crayford focuser for precise focusing with locking screw
• 1.25" connector and T2 connector for screw adaptations
• sufficient working distance for use of 1.25" amiciprism, zenith prism and of course photo adapters
• finder shoe for direction finders, optical finders or mini guide scopes
• Carrying case with plenty of space for accessories
• Retractable dew cap - transport length only 310 millimeters
• High quality workmanship "Made in Taiwan"

The TS Photoline 1.0x full-frame flattener corrects the field of view of refractor telescopes and allows astrophotography with perfect edge sharpness

• Full illumination and correction of the image field up to 55 mm sensor diameter
• Factor 1.0x, the focal length remains unchanged.
• Suitable for all refractor telescopes with focusers from 2.5" upwards
• No reflections and ghost images due to high quality coating and anti-reflection thread
• Connections at the telescope side M68x1 male thread and M63x1 male thread (reducing adapter)
• Connections at the camera side M48x0.75 male thread with adaption for 2" filter
• Practical working distance of 55 mm from M48 thread (can be extended to 88 mm)
• Refractors require a working distance of at least 145 mm from the M68 or M63 female thread.
