The Altair AA533MTEC features a 14-bit Sony IMX533 backside illuminated sensor with very high sensitivity.
Lower read noise and higher sensitivity easily outperform front illuminated CCD cameras at a more competitive price.
Zero Amp Glow makes the AA533MTEC a pleasure to use and the 3.76um square format pixels make it easy to frame targets, especially galaxies!
2-stage TEC cooling reduces thermal noise to negligible levels and the camera sensor is guaranteed against freezing for two years due to the special chamber design. A heated, anti-reflective coated optical window reduces the risk of condensation on the front glass.
Scope of Delivery:
Products specifications
| Cooling | 2-stage Peltier Cooling |
| Shutter | Rolling Shutter, Progressive Scan |
| Pixel | 9 Mp |
| QE | >80% |
| Backfocus | 17.5mm |
| Pixel size | 3.76µm |
| Maximum exposure length | 0.1ms ? 3600secs |
| ADC | 14bit |
| Power | 12V, 3A |
| Connection to telescope | M42x0.75 Female |
| Sensor Type | Background Illumineted CMOS monochrome chip |
| Sensor size | 15,9 mm Diagonale |
| Horizonal Resolution | 3000 Px |
| Vertical Resolution | 3000 Px |
| Weight | 550g |
| Pixel fullwell capacity | 50,3 ke |
| Sensor type | Sony IMX533 Mono CMOS Back Side Illuminated |
