Apochromatic Refractor AP 130/780 LZOS 3.7-ZTA OTA

Apochromatic Refractor AP 130/780 LZOS 3.7-ZTA OTA

Apochromatic refractor AP 130/780 LZOS 3.7-ZTA OTA

  • Our LZOS Super ED 3-lens models come with a test report, meaning that each lens is individually measured using a Twymann interferometer and recorded with the serial number of the lens.
  • Maximum Strehl ratio (as with the Zeiss APQ) is guaranteed to be 95% or better.
  • Residual chromatic aberration optimized to a minimum.
  • Temperature-compensating mount.
SKU : APM 130_780 LZOS 3.7-ZTA_OTA
Price: 6095.00 € incl tax 19% (Germany)
Product description

The 130 mm f/6.0 APM LZOS Triplet SuperED Apo is one of the world's best telescopes in terms of quality and imaging performance. With f/6, it is in the optimal mid-range for both visual and astrophotographic use. In just a few simple steps, you can transform this instrument from a very good planetary telescope into a high-quality astrograph. The back focus is fully sufficient for binoculars or long astrophotographic image trains.

The high-quality multi-coating and the optimised interior of the tube contribute significantly to the overall result.

An interferometric test report is included in the scope of delivery, providing information about the exact optical performance data.

The basic equipment of the telescope is already quite extensive and includes, for example, a Losmandy rail, CNC tube clamps, a finder shoe and a sturdy case.

 Optic
 Typ Refractor
 Design Apochromat
 Diameter (mm) 130
 Focallength (mm)780
 Focalratio (f/) 6
Resolution (arcsec)1,06
Visual limit (mag) 12,4

light gathering power (-x 7mm Pupille)

340
Vmax260
Tube Wight (kg) 10
Tubelenght (mm) 830
Lenght Max (mm) 680
Lence designTriplet
Coating FMC
Tube material Aluminium
Focuser
Diameter  (mm) 94
Connecting (Zoll) 2
Reduction1:10
Rotating Yes
Anschlussgewinde (kameraseitig) M75
Backfocus (mm) 180

Included accessories

  • Prism rail, Losmandy style
  • Finder shoe, Vixen/Skywatcher Level
  • Eyepiece adapter, 2"/ 1.25"
  • Tube rings
  • Dew cap
  • Carrying handle
  • Transport case
