Mounts & Tripods

Light and flexible dovetail bar with oblong holes, countersunk hole and 1/4" photo thread

• Suitable for adapting telescopes and photo lenses to mounts and dovetail clamps with Vixen and EQ5 level quick release
• Also suitable for photo tripods, tilt heads and ball heads via the 1/4" photo thread in the middle
• Two oblong holes with 100mm length each, suitable for 1/4" and M6 hexagon socket screws
  Length of the dovetail bar: 300 mm
• Thickness of the dovetail bar: 14 mm (profile construction)

• 3/8" photo thread at the top - suitable for all mounts with a flat bottom and 3/8" internal thread
• Also suitable for ball heads and tilt heads
• Suitable for piers with an inner diameter of 93.5 mm, such as the TSPIER piers
• Distance of the three fastening screws on the pier from the stop edge 16.5 mm
• With 3/8" photo screw
• Made of aluminium - black anodized

• Suitable for Skywatcher mounts EQ3, EQM35, EQ5, AZ-EQ5, HEQ5
• Suitable for Vixen GP mounts
• Suitable for Bresser Mon2 mounts
• Suitable for piers with the inner diameter of 93.5 mm
• Outer diameter of the support plate 100.5 mm
• Distance of the three fixing screws on the column from the stop edge 16.5 mm
• With fixing screw for the mounting and the spigot for the azimuth fine adjustment
• Solid aluminium

• Suitable for Skywatcher EQ6 and Celestron CGEM mounts
• Suitable for piers with an inner diameter of 93.5 mm, such as the TSPIER piers
• Distance of the three mounting screws on the pier from the stop edge 16.5 mm
• With fastening screw for the mount and the pin for azimuth fine adjustment
• Made of aluminium - black anodized


The weatherproof pillar tripod is not only stable, but often also allows the telescope to be swivelled through where a tripod would already be at a standstill.

• Steel pillar - weatherproof
• Three outriggers with levelling screws - this allows you to set the device exactly level (levelling)
• The stabilisers can be easily removed from the column for easier transport
  Height 1000 mm
• Outer diameter 100 mm / wall thickness 5 mm
• Suitable mounting adapters are optionally available (see accessories)

The weatherproof pillar tripod is not only stable, but often also allows the telescope to be swivelled through where a tripod would already be at a standstill.

• Steel pillar - weatherproof
• Three outriggers with levelling screws - this allows you to set the device exactly level (levelling)
• The stabilisers can be easily removed from the column for easier transport
  Height 1200 mm
• Outer diameter 100 mm / wall thickness 5 mm
• Suitable mounting adapters are optionally available (see accessories)

The weatherproof pillar tripod is not only stable, but often also allows the telescope to be swivelled through where a tripod would already be at a standstill.

• Steel pillar - weatherproof
• Three outriggers with levelling screws - this allows you to set the device exactly level (levelling)
• The stabilisers can be easily removed from the column for easier transport
  Height 500 mm
• Outer diameter 100 mm / wall thickness 5 mm
• Suitable mounting adapters are optionally available (see accessories)

The weatherproof pillar tripod is not only stable, but often also allows the telescope to be swivelled through where a tripod would already be at a standstill.

• Steel pillar - weatherproof
• Three outriggers with levelling screws - this allows you to set the device exactly level (levelling)
• The stabilisers can be easily removed from the column for easier transport
  Height 700 mm
• Outer diameter 100 mm / wall thickness 5 mm
• Suitable mounting adapters are optionally available (see accessories)

Adapter for Celestron AVX Goto mounts to the TS Tri-Pier pier stand and also for DIY.

• The adapter fits to the Celestron AVX mount.
• Matching stainless steel counter screws and two pins for azimuth adjustment of the mount are included.
• The adapter is optimized for the Celestron AVX mount.
• Diameter at the bottom is 93.8 mm - fits the TS-Optics Tri-Pier pier tripod - also ideal for DIY with a pipe as pier.

Adapter for iOptron mounts to the TS Tri-Pier pier tripod and also for do-it-yourself.

• The adapter fits to iOptron mounts CEM70(G), CEM60(G), CEM40(G), CEM45(G), CEM26 and CEM28
• Matching counter screws and the pin for the AZ adjustment are included
• Diameter at the bottom is 93.8 mm - fits the TS-Optics Tri-Pier pier tripod - also ideal for DIY with a pipe as pier.
• Diameter at the top is 149 mm

Adapter for EQ6, EQ-5, H-EQ5, CGEM ... mounts to the TS Tri-Pier pier stand and also for DIY.

• The adapter fits to Skywatcher mounts EQ3, EQ5, H-EQ5, EQ6, AZ-EQ6 and EQ6-R mounts.
• The adapter fits Celestron CGEM mounts.
• The adapter fits Bresser / Meade Exos-2 mounts and similar
• Matching M10 and M12 stainless steel counter screws and two mandrels for azimuth adjustment of the mount are included.
• Three different distances from the center to the azimuth adjustment are available
• Diameter at the bottom is 93.8 mm - fits the TS-Optics Tri-Pier pier tripod - also ideal for DIY with a pipe as pier.
• Diameter at the top is 115 mm

Adapter for Vixen mounts to the TS Tri-Pier pier stand and also for DIY.

• The adapter fits many Vixen mounts with the GP type tripod connection.
• Matching stainless steel counter screws and two pins for azimuth adjustment of the mount are included.
• Two different distances from the center to the azimuth adjustment are available.
• Diameter at the bottom is 93.8 mm - fits the TS-Optics Tri-Pier pier tripod - also ideal for DIY with a pipe as pier.

The adapter allows the connection of ball heads, tilt heads and AZ mounts with the 3/8" photo thread to the TS Tri-Pier pier stand and also for DIY.

• The adapter has a 3/8" photo thread (male thread ) on the top side.
• Diameter at the bottom is 93.8 mm - fits the TS-Optics Tri-Pier pier tripod - also ideal for DIY with a pipe as pier.

The tripod is designed for Skywatcher EQ6, H-EQ5 or EQ5, Celestron CGEM or iOptron mounts and can be loaded up to 100 kg.

• Working height 950 mm
• High quality 6061T aluminum and stainless steel
• Weight only 8 kg
• Flexible like a tripod, but stable like a pier
• Ideal for astrophotography because telescopes do not hit the tripod legs, photography well past meridian is possible.
• The legs can be folded for transportation
• There is a leveling device with a counter screw on each leg
• High-quality transport bag is included in scope of delivery
• Adapters for mounts are optionally available
