Refractors

120mm (4.75”) f/900 ED Apochromatic Refractor Telescope

• 120 mm aperture, 900 mm focal length, focal ratio f/7.5
• High image quality thanks to extra-low dispersion glass FPL53 (Ohara, Japan) and matching glass from Schott
• Highly effective coating for maximum transmission and minimum reflections
• Large Crayford focuser with 11:1 reduction for sensitive focusing
• 360° rotation adapter
• Tube in traditional white - heats up less during the day and is more visible at night

Fast 70mm high-performance astrograph F5.5 for demanding astrophotographers and observers with 5 lens elements in 5 groups

• Very fast 70mm high-performance astrograph for demanding astrophotographers
• Due to the large lenses there is almost no vignetting
• Complex construction with 5 lens elements in 5 groups for absolute correction
• Needle-thin stars up to the edge of the image field even with 44 x 33 mm camera format
• Large, stable eyepiece extension, also suitable for heavy cameras
• Extremely high sharpness, colour purity and contrast thanks to SD lenses
• Very large field illumination up to 55mm
• High Strehl intensity of 96.7% at visible wavelengths
• Optional reducer available for even faster results
• Optional motor focuser with two speeds can be retrofitted

The powerful ED apo is suitable for observing and astrophotography with an high-contrast image.

• 150 mm aperture, 1200 mm focal length, focal ratio f/8
• High image quality thanks to extra-low dispersion glass FPL53 (Ohara, Japan) and matching glass from Schott
• Highly effective coating for maximum transmission and minimum reflections
• Large rack and pinion focuser with 11:1 reduction for sensitive focusing
• 360° rotation adapter
• Tube in traditional white - heats up less during the day and is more visible at night

Takahashi offers rotating camera mounts for its telescopes, which are necessary because most of the company's focusers are not rotatable. However, this rotator also makes sense visually, as it allows the ZSP or other accessories to be conveniently rotated into the desired position. The quality is so high that there is no play even when the screw is loosened.

• Connection on the telescope side: M56x0.75 internal thread
• Connection on the camera side: M56x0.75 external thread
• Light path: 12.3 mm
• Weight: 110 g

The Esprit-70EDX from Skywatcher offers the highest optical and mechanical quality and is optimized for astrophotography.

• Aperture 70 mm
• Focal length 490 mm (f/7)
• Triplet apo objective with FCD100 ED element
• Improved 2.8" dual-speed focuser for high payload
• 360° rotation
• 2" connection with additional thread for screw adaptations
• Retractable dew shield
• Carrying handle, Vixen GP style dovetail bar, carrying case

Takahashi offers matching 1:7 microfocusers for all telescopes with normal focusers.

• TOA-130(N)S
• TSA-102, TSA-120
• FC-76DS, FC-76DC
• FS-60CB, FS-60Q, FS-60C, FOA-60(Q)
• FS-60CB, FC-76DP
• SKY90
• FS-78, 102, 128N
• FC-65, 76, 100, 100N, 125N
• FCT-65
• MT-130, 160, 200
• Epsilon 130, 160, 180
• Mewlon mit Okularauszug TKA00700

The Esprit-100EDX from Skywatcher offers the highest optical and mechanical quality and is optimized for astrophotography.

• Aperture 100 mm
• Focal length 550 mm (focal ratio f/5.5)
• Triplet apo objective with FPL53 ED element
• Improved 3" dual-speed focuser for high payload
• 360° rotation
• 2" connection with additional thread for screw adaptations
• Dew shield (fixed)
• Carrying handle, Losmandy style dovetail bar, carrying case
