New Vixen SD103SII apochromatic high-performance refractor with FPL53 SD glass and improved optical properties for demanding observers and astrophotographers

• Apochromatic high-performance refractor with FPL53 ED glass
• Reduces chromatic aberration to an absolute minimum
• Guarantees enormously high contrast and excellent sharpness
• You get a very colour-pure, sharp and neutral image
• Very light and transportable, ideally suited for mobile applications
• Fully-coated 103 mm SD lenses without spacer plates
• No more unwanted spikes visible on the stars
• High-quality standard "Made in Japan"
• Dimensions: 115 x 810 mm
• Weight: 5.5 kg with accessories

The Vixen SD103S is a new high-performance Super ED apochromat that produces sharp, high-contrast and true-colour images

• Apochromatic refractor
• High-performance Super FPL-53 ED glass lens
• Short overall length and low weight
• Ideal for planetary observation and photography
• Illumination with a 44mm image circle for full format
• Ideal travel equipment for observation and photography
• Solid quality MADE IN JAPAN

The 80PHQ is a very transportable APO refractor for astrophotography with corrected field of view up to full frame format and for observing up to the highest magnification range.

• Aperture 80 mm / focal length 600 mm / focal ratio f/7.5
• 4-element Petzval system with color clean triplet objective and one corrector lens built into the tube
• Stable 3" RAP focuser with dual speed and 360° rotation
• Sufficient working distance for observation with 2" accessories
• Suitable photo adapters are included in delivery
• Illuminated image circle with very good correction up to full frame format
• CNC tube rings with Vixen style EQ5 dovetail bars and carrying handle
• Finder shoe for standard finder and mini guiding telescopes available
• High quality carrying case for optimal protection of the telescope
• Each Quadruplet Apo is inspected upon receipt, you will receive an optimally adjusted telescope for successful photography and observation from the very beginning.

TS PHOTOLINE 96 mm f/6 triplet apochromat with color-clean image - high quality triplet objective from Japanese production.

• Aperture 96 mm / focal length 576 mm / focal ratio f/6
• Multi-coated 3-element lens with FCD100 APO element (similar to FPL53) from Hoya (Japan) for a color-pure image
• Lens including cell is made in Japan
• Internal baffles for higher contrast and against reflections
• 2.5" RAP dual-speed focuser with improved draw tube bearing - carries accessories up to 10 kg without shifting
• Connection for screw adaptations via M63x1 female thread, 2" and 1.25" receptacle
  Retractable dew shield for transport
• CNC tube rings, Vixen/EQ5 style dovetail bars on both sides and finder shoe are included in delivery
• Each apo is tested and optimized at our optical bench before shipping

William offers with the REDCAT71 Astrograph a very well corrected telescope for astrophotography up to full frame format.

• Aperture 71 mm / Focal length 350 mm / Focal ratio f/4.9
• Petzval design with chromatic aberration free FPL53 objective (4 elements in 3 groups)
• Very well corrected and illuminated image field up to full frame format - the corrector is built in - no more adapter battle necessary
• Camera connection via M48 male thread (suitable adapters are available) - working distance 55 mm
• 360° rotation of the camera for the right display window
• Focusing via precise helical focuser like telephoto lenses
• Tilting option for individual adjustment of the camera sensor to the telescope
• Flexible dovetail bar at the base (long version), suitable for Vixen style and Arca-Swiss saddle plates, in addition with 1/4" female photo tripod thread
• Nylon carrying bag and Bahtinov mask for astrophotography are included in delivery

Newtonian telescope with 6" aperture and 600 mm focal length individually made for you in Germany with high quality carbon tube - an ideal travel telescope and for astrophotography

• Aperture 150 mm / focal length 600 mm / focal ratio 1:4
• Three focus positions built in - simply by moving the main mirror, thus all correctors, also focal reducers, can be used
• Stable, 4 mm thick carbon tube for maximum rigidity and adjustment stability
• TS UNCN2-G2 ball bearing RAP focuser with screw possibility for photo adaptations - optimal for photography and observation - of course motorizable
• Valuable lightweight rings and tube end pieces - individually manufactured for this telescope.
• TS "Black" anti-reflective paint provides a dark tube and prevents annoying reflections
  Selected quality optics for best imaging
• 94% reflection on primary mirror and secondary mirror for a brighter, high contrast image
• Stable collimatable primary mirror mount, specially made for this telescope
• Each ONTC Newtonian is tested on the optical bench of Teleskop-Service before shipment - delivery with production protocol
• The tube rings and the end pieces are also manufactured in black on request.
• Made in Germany

The TS 102 mm f11 SDP Apo offers excellent chromatic aberration correction by pairing FPL53 with additional special glass

• Very good correction of chromatic aberrations by a 2-element APO lens with FPL53 from Ohara and an additional special glass
• Very good correction also in the violet color range, where faster SD-Apos give in a bit
• Even at 250-300x sharpness is maintained
• Adjustable lens mount
• Improved 2.5" rack and pinion RAP focuser with photo thread, 2" and 1.25" adaption
• Retractable dew shield for better transport and optimal protection against stray light
• Deluxe finder holder for adapting finder telescopes
• Binoviewers can be used without path compensation
• CNC tube rings and EQ5 style dovetail bar included
• With only 4.6 kg the ED is well supported by mounts like the Skywatcher EQ5
• Each TS Apo is individually tested before shipping (optics, mechanics, cosmetics), a checklist is attached.

The ASKAR APO 72 mm f/5.6 quintuplet apochromat from Sharpstar is optimized for astrophotography with high resolution cameras

• Aperture 72 mm
• Focal length 400 mm / focal ratio f/5.6
• 5-element quintuplet design with corrector in tube
• Two ED glasses in the objective for very good correction of the chromatic aberration
• 44 mm image circle with full illumination and correction
• 140 mm working distance for visual observation or focal length reduction
• Stable 3" dual-speed RAP focuser with 360° rotation
• 2" and 1.25" receptacles as well as M68x1 external thread for screw adaptations
• Long adapter from M68 to M48x0.75 camera connection is included in delivery (with 2" filterthrad)
• Flexible GP/EQ5 style dovetail bar with photo tripod connection and carrying handle with flexible slotted hole
• Finder shoe for standard finder holder
• Including inspection check list of the manufacturer

The fast 110 mm ED APO offers good chromatic correction through two special glasses, it is designed for observation and astrophotography.

• Aperture 110 mm / focal length 660 mm / focal ratio f/6
• 2-element APO objective with FPL51 and Lanthanum glass from Ohara-Optics
• Full multicoating for high contrast
• 2.7" RAP focuser with ball bearing, 360° rotation and micro reduction
• M74x1 female thread for screw adaptions
• CNC tube rings - aluminium tube - retractable dew shield
• Aluminium carrying case
• Made in Taiwan
