TS-Optics Dual Vixen Losmandy Style Dovetail Clamp

TS-Optics Dual Vixen Losmandy Style Dovetail Clamp

The TSPKLV premium clamp accepts Losmandy and Vixen / EQ5 style dovetail bars. It is also suitable for heavy telescopes.

  • Length 150 mm / Width 102 mm / Height 30 mm
  • Surface clamping for gentle and firm fixation of the dovetail bars
  • Weight 986 gram
  • Solid aluminum construction - no twisting - load capacity up to 20 kg without problems
  • Four countersunk slotted holes for flexible attachment to mounts or plates
Manufacturer : TS Optics
SKU : TSO-TSPKLV
Price: 109.24 € excl tax
Delivery date : 1-4 days
Product description

TS Premium Dovetail Clamp for Losmandy and Vixen Style Dovetail Bars

With this saddle plate, you can equip your mount with a flexible quick coupling with high load capacity. However, the saddle can also be adapted to dovetail bars or individual plates. The attachment is particularly flexible and stable due to four slotted holes.

The TSPKLV saddle plate accepts Losmandy and Vixen style dovetail bars. This allows you to change different telescopes within a few minutes. Due to the saddle´s length of 150 mm, even long-building telescopes are clamped securely, without twisting and disturbing vibrations.

Scope of Delivery:

  • Dovetail Clamp
Products specifications
Length150mm
Width102mm
Height30mm
Suitable forVixen Mounting bar
