Vixen Focal Reducer V0.71x VSD90ss/VSD70ss

Vixen Focal Reducer V0.71x VSD90ss/VSD70ss

Focal length reducer for VSD90ss and VSD70ss with two ED lenses for high-end astrophotography and an illumination of 44 mm for full-frame cameras

  • Elaborately designed focal length reducer for the VSD90ss/VSD70ss
  • Suitable for a 24x36 full format camera
  • Four lens elements in four groups for exceptionally sharp star images
  • Guarantees a large illumination of the image field up to 44 mm
  • Very sharp stars up to the edge of the field of view
  • The VSD90ss thus allows extremely short exposure times
  • High-quality standard ‘Made in Japan’
  • Reduces the focal ratio of the VSD90ss from f5.5 to f3.9
  • Dimensions: 92 mm diameter x 59.2 mm length / Weight: 589 g
SKU : BR-X026638
Price: 1249.00 € incl tax 19% (Germany)
Estimated delivery time : 3-4 weeks
Product description

Focal length reducer for the VSD90ss and VSD70ss with two ED lenses designed for high-end astrophotographyThe two ED lenses maximise the photographic performance of the VSD90ss and the VSD70ss, which are designed for both photography and visual observation. The reducer can illuminate an image circle of 44 mm (suitable for a 34x36 full-frame format). The reducer has a very sophisticated design as it contains four elements in four groups, including 2 ED lenses. Thanks to its larger lens diameter, it offers significantly improved image illumination compared to its predecessor, the smaller V0.79x reducer. The star distortion at the edges is also reduced to an absolute minimum.The focal length of the VSD90ss telescope is shortened by about 0.71x and the focal ratio is reduced from 5.5 to 3.9. This results in a super-fast f3.9 astrograph, capable of fully illuminating a full-frame DSLR camera.

FEATURES

  • Magnification: 0.71x
  • Focal length VSD90ss: from 495 mm (F5.5) to 351 mm (F3.9)
  • Illumination: 44 mm
  • Lens design: 4 elements in 4 groups, including 2 ED lenses
  • Coatings: AS coatings (99% light transmission per surface)
  • Connection thread: M84mm, pitch 1 mm (male thread)
  • Connection thread for a camera: M60 mm, pitch 0.75 mm
  • Filter thread: 60 mm diameter

SCOPE OF DELIVERY

  • Focal Reducer V0.71x
  • 2 mm Allen keys
  • Dust caps
Batteries included:No
Batteries required:No
Colour:black
Material:Aluminium
Net weight (without access.) (g):589
Power supply unit included:No
Total height (mm):59
Total length (mm):92
Total width (mm):92
